ASUS MB Sc LGA1200 PRIME H410M-K R2.0, Intel H470, 2xDDR4, 1xHDMI, 1xDVI, mATX

Socket (patice):Socket 1200; Formát:micro ATX; Integrovaná grafická karta; Chipset:Intel; Technologie paměti RAM:DDR4; PCI express 16x:1; Integrovaná LAN karta:1; Rozhraní:HDMI, USB 2.0, USB 3.2, 3.5mm Jack, LAN, DVI.... více
Běžná cena: 1 790  (-2%)
1 442.98 Kč bez DPH
Skladem > 5 ks
1 746 Kč
ks
Vyberte si zvýhodněné balení
Množstevní slevy
Kód: 431522
Kód dod.: 90MB1A70-M0EAY0
EAN: 4711081364382
Záruka: 36 Měsíc(ů)
Výrobce: Asus
Popis a parametry

ASUS MB Sc LGA1200 PRIME H410M-K R2.0, Intel H470, 2xDDR4, 1xHDMI, 1xDVI, mATX

PRIME H410M-K R2.0

Intel® H470 (LGA 1200) micro ATX motherboard with M.2 support, 8 power stages, HDMI, DVI, SATA 6 Gb/s, front USB 3.2 Gen 1, Intel® 1 Gb Ethernet, PCIe 3.0, Intel® Optane™ Memory Ready, ASUS OptiMem, FAN Xpert, Armoury Crate, 5X PROTECTION III

  • Intel® LGA 1200 Socket: Ready for 10th Gen Intel® Core™ processors
  • Enhanced Power Solution: 8 power stages, alloy chokes and durable capacitors for stable power delivery
  • Comprehensive Cooling: PCH heatsink, fan headers and Fan Xpert
  • ASUS OptiMem: Careful routing of traces and vias to preserve signal integrity for improved memory stability
  • Ultrafast Connectivity: M.2 support, Intel® 1 Gb Ethernet, and USB 3.2 Gen 1

CPU

Intel® Socket LGA1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
Supports Intel® 14 nm CPU
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to www.asus.com for CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset

Intel® H470 Chipset

Memory

2 x DIMM, Max. 64GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem
* 10th Gen Intel® Core™ i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.

Graphics

1 x DVI-D
1 x HDMI 1.4
* Graphics specifications may vary between CPU types.

Expansion Slots

1 x PCIe 3.0 x16 (x16 mode)
Intel® 10th Gen Processors
1 x PCIe 3.0 x16 slot (supports x16 mode)
Intel® H470 Chipset
2 x PCIe 3.0 x1 slots

Storage

Supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
Intel® H470 Chipset
M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)
4 x SATA 6Gb/s ports
Intel® Rapid Storage Technology supports RAID 0,1,5,10
Intel® Optane™ Memory Ready

Ethernet

1 x Intel® 1Gb Ethernet
ASUS LANGuard

USB

Rear USB:Total 6 ports
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB:Total 6 ports
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports

Audio

Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium Japanese audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Back Panel I/O Ports

4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DVI-D port
1 x HDMI port
1 x Intel® I219-V 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port

Internal I/O Connectors

Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
1 x M.2 slot (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Miscellaneous
1 x Clear CMOS header
1 x Front Panel Audio header (AAFP)
1 x S/PDIF Out header
1 x SPI TPM header (14-1pin)
1 x 20-3 pin System Panel header with Chassis intrude function

Special Features

ASUS 5X PROTECTION III
- DIGI+ VRM
- LANGuard
- Overvoltage Protection
- SafeSlot Core
- Stainless-Steel Back I/O
ASUS Q-Design
- Q-DIMM
- Q-Slot
ASUS Thermal Solution
- Aluminum heatsink design

Software Features

ASUS Exclusive Software
Armoury Crate
AI Suite 3
- Performance and Power Saving Utility
TurboV EVO
EPU
DIGI+ VRM
FAN Xpert
- EZ update
ASUS CPU-Z
AI Charger
DAEMON Tools
Norton Anti-virus software (Free Trial version)
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode

BIOS

128 Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x I/O Shield
1 x M.2 ANCHOR
Installation Media
1 x Support DVD
Documentation
1 x User manual

Form Factor

microATX
24.4cm x 24.4cm

.
Technologie paměti RAM
DDR4
Rozhraní
3.5mm Jack
Socket (patice)
Socket 1200
Formát
micro ATX
Integrovaná grafická karta
Ano
Chipset
Intel
PCI express 16x
1
Integrovaná LAN karta
1
