Technické specifikace

• Application: Client PCs
• Capacity: 500GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
• Form Facto: rM.2 (2280)
• Interface: PCIe Gen 4.0 x4, NVMe 1.3c
• Dimension (WxHxD): 80.15 x 22.15 x 2.38 (mm)
• Weight: Max 9.0 g Weight
• Storage Memory: Samsung V-NAND 3-bit MLC
• Controller: Samsung Elpis Controller
• Cache Memory: Samsung 512MB Low Power DDR4 SDRAM
• TRIM Support: Supported
• S.M.A.R.T Support: Supported
• GC (Garbage Collection): Auto Garbage Collection Algorithm
• Encryption Support: AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
• WWN Support: Not supported
• Device Sleep Mode Support: Yes
• Sequential Read: Up to 6,900 MB/s * Performance may vary based on system hardware & configuration
• Sequential Write: Up to 5,000 MB/s * Performance may vary based on system hardware & configuration
• Random Read (4KB, QD32): Up to 800,000 IOPS* Performance may vary based on system hardware & configuration
• Random Write (4KB, QD32): Up to 1,000,000 IOPS * Performance may vary based on system hardware & configuration
• Random Read (4KB, QD1): Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
• Random Write (4KB, QD1): Up to 60,000 IOPS * Performance may vary based on system hardware & configuration
• Average Power Consumption (system level): *Average: 5.9 W *Maximum: 7.4 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
• Power consumption (Idle): Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration
• Allowable Voltage: 3.3 V ± 5 % Allowable voltage
• Reliability (MTBF): 1.5 Million Hours Reliability (MTBF)
• Operating Temperature: 0 - 70 ? Operating Temperature
• Shock: 1,500 G & 0.5 ms (Half sine)
• Installation Kit: Not Available
• Management SW: Magician Software for SSD management
